领域与简单介绍/Brief Introduction：

全全自功注塞泵泵式膏体酱包电脑装机我大公司适用于领域供给研发的新商品设备。该设备运用SUS304不銹钢注塞泵泵式计量检验泵制定彩盒，且集全自功上盖、全自功旋盖、电器设备电器设备为立体式，金钱通用性，拆迁赔偿占地面小，大面积利用于医药集团、产品、药剂、化工公司、美容品等相关行业的透明液体彩盒，符合规范GMP规范性规范。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

显著特点/characteristic：

◆选取注塞泵式剂量泵来执行灌装设备，可用一些黏黏度全自动，精准程度高；泵的型式选取快接式拆开医院，为了方便洗涤、酒精消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆柱塞泵式计量检测泵缸筒环原材料表明业及介质成份的区别进行硅再生胶，四氟氯乙烯或其它的原材料，专项 场所进行陶瓷图片原材料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC掌控系统，交流变频变频调速，一键化度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不罐装，会自动计数器的功能。Lack of bottle filling, automatic counting function◆装量调准简单方便，可是一次调准全部都量值溯源检定泵的充填量，也可面向各量值溯源检定泵实现微幅调准；操作的简变，调准迅速的。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆分装针头均有防漏滴设备，充填时前往瓶底分装，很快变高，解决泡泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆一整台机器的可适用于其他样式的矿泉水瓶，调整操作简单，可在短期间内完全。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆服务器按GMP请求设汁。The machine designed according to the requirements of GMP

水平参数表/technic parameter：

使用空瓶规格型号Size of bottles	20-1000ml（据想要订制）20-1000 - ml (according to your need）
采用瓶盖孔径Apply the bottle diameter	¢20-¢150mm
符合盖子要求Apply the lid specifications	¢20-¢70mm
加工力量 production capacity	四头罐装：1000-2500瓶/h Four filling head: 1000-2500 bottles per hour 八头罐装：2500-4000瓶/h Eight head filling: 2500-4000 bottles per hour 12头罐装：4000-6000瓶/半小时 12 head filling: 4000-6000 bottles per hour
装量误差值The load error	±1%
旋盖及格率Screw cover percent of pass	≥99%
外接电源power supply	380V，50HZ
工率power	3.0KW
氧气源gas sources	0.4-0.75MPA
快速设定speed control	调频调压variable speed
