作用与概况：Purpose and introduction

该设配不适于对30-500ML系列的玻璃钢瓶、pp可乐瓶的包装封膜。选取往来账过往式活塞环进行包装，电磁能自由振荡送盖，就能否轧盖(合金材料式)或旋盖(pp朔胶盖)封膜，就能否和前后的的产出制作工序设配连接起来成分产出线，还有就能否够买百级层流罩。This machine is suitable for the filling and sealing of 30-500ml series glass bottles and plastic bottles. The reciprocating between piston filling, electromagnetic oscillation send cover, cover (metal) can be rolled or screw cap (plastic cap) sealing. Can produce and the produce of the process equipment before and after connecting line. In addition, the laminar flow hood is available for selection.

特殊性：characteristic

装量准确度，杜尽渗漏。缺瓶不分装。 调频变速。 积极主动现示记数效果。 主机均按GMP条件制定。The filling amount is accurate, as Du drip. Lack of bottle does not fill. Frequency control of motor speed. Active display count. The machine according to the GMP request design.

技術运作/technical parameters：

型号 model	NQGX30-500
适用人群规格尺寸Cutting dimension	30-500ml
加工性能Production capacity	80-200瓶/分（罐/多分钟）80-200 bottles/min (cans/min)
灌装线要求 Filling accuracy	≤±1%
24v电源 Power	380V/50Hz
旋（轧）盖率Spin (rolling) cover rate	≥99%
功率power	3.0 kw
机重量 Machine weight	1500 kg
外形尺寸 boundary dimension	3000*1100*1700mm
