贷款用途与百度百科/Purpose and introduction：

NQGF型西林瓶粉针洗烘分开装袋轧盖标贴连动线 由QCL品类直列V型超声检查洁净波洗瓶机、AQMR队道式自动空调不断间歇杀菌干燥箱、NQFGX品类数控车床丝杠粉剂分开装袋机、NQ-50轧盖机、NQWTB-120标贴超临界锅炉成，也可pc单机用到。最合适于7-25ml金桥铜业跨接线的截面积大小的西林瓶粉针的产生。能成功喷淋头加压、超声检查洁净波粗洗、瓶侧壁水冲刷、瓶壁上累计二级不断间歇水冲刷、一遍吹气、一遍新鲜度水冲刷、累计二级吹气、瓶侧壁吹气、洁净、点火、吹干杀菌去热原、空气冷却、分开装袋、加塞、轧盖、标贴等二十几道工艺流程。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

优点和缺点/characteristic：

◆洗瓶机采用了设备手夹瓶，选用三种产品规格的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶主要包括水汽喷针循环往复跟踪目标加上途径，拆洗功能好，避免浪费再生资源。并有针架防颤动装置设备，从而提高喷针加上玻璃瓶的合理度，极大减少断针表现再次发生；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶整体的水雾管道、喷针完整独立性分离开来，解决了交叠废弃物，符合国家GMP规范了想要；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶螺丝杆前还可以加装响应块，有护理螺丝杆，抑制碎瓶功效；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶进行综合进囗的微信同步带，接触拨瓶块气流输送西林瓶，运动不稳靠普；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆干燥箱运用自动空调循坏热处理加热，温透亮，能源管理；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆真空烘箱均有防有时候停电保護功能性。启动应急；Mixer oven has suddenly loses power protection function. Run security;◆烘烤箱可配循坏风冷传动装置，不消耗的资金屋内内风速，缩短屋内内的气体压力不稳定的风险分析散热功能好；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆真空烘烤箱可配压力自然静态失衡调接整体减掉房和真空烘烤箱的压力不静态失衡会导致的高温天气段偏斜，装罐间洗烘间温暖升高等学校一系统的现象；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆恒温干燥箱安装有DOP测量音频接口(有风压气压、风速等级、浮尘a粒子测量口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆烤箱放置冷却段可带同屏在线过滤除菌能力(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆烤箱网带可带彩超涉及CIP百度在线洗掉整体；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆恒温干燥箱内腔室可参与全定位、多的视角低压水擦洗；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆散装机选用全球更较为先进的设计以人为本，有着快快速，可是分瓶准确的，换个规格型号件便捷；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆分开包装机选取交流沟通电动机驱动安装器电动机驱动安装分开包装丝杠翻转，装量小于；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆分开装袋机所采用装量的校准进行在触屏屏上确保；Mixer packer adopts the load adjustment directly on a touch screen;◆分开包装机可以配百级再循环式层流罩；Mixer packer optional circulating laminar flow hood best level;◆散装机无瓶停掉散装，无瓶不带塞功能表。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线采取PLC总把控、直流变频空调器、触屏屏把控高技术，运动相对稳定稳定。触屏屏可显现各单机版的运动情况，各把控点的静水压、大气压、静压、温等显现，各启闭情况和错误码显现，错误码自鉴别诊断和错误码了解及确诊措施。使一整块生產流程达到了电脑电气自动化把控，联线拥有自动控制稳定仪器，维持生產均匀稳定。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.随着老客户的需要，还可供选购：According to the needs of customers, but also available for selection:◆simens、斯耐德、西门子、台达等产品品牌操纵平台；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气心理压力、水的温度及超音波波力度、浮尘粒子束、风压线上论文检测、報警、统计、打印文件系统化；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、无菌检测隔離器程序。ORABS, CRABS, aseptic isolator system.

技能技术指标：/technical parameters

具体型号 model

加工性能production capacity

洗瓶合理率Washing bottle percent of pass

洗瓶开裂率Washing bottle breakage

灭菌方法平均温度sterilizing temperature

全自动灌装机出现偏差的原因The repackaging of error

加塞达标率率Gasser percent of pass

冷空气层流超纯净度Laminar air cleanliness

蒸空抽速Vacuum pumping speed

电解电容量 capacitance

电源适配器power supply

总电容量Total transmission energy

形态规格boundary dimension

7-25ML国家标准西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
